lm324n quad operational low power amplifier ic dip 14

LM324N Quad Operational Low Power Amplifier IC DIP-14

Sold: 0

₨35

LM324N LM324 is low power quad operational amplifier. LM324N consist of four independent, high gain, internally frequency compensated operational amplifiers.

Original quality products. Easy return in 7 days.
Estimated Delivery: within 2 working days.
SKU: LM324NDC Category: Tags: ,

Description

  • Wide gain bandwidth: 1.3MHz
  • Input common-mode voltage range includes ground
  • Large voltage gain: 100dB
  • Very low supply current/ampli: 375µA
  • Low input bias current: 20nA
  • Low input offset voltage: 5mV max. (for more accurate applications, use the equivalent parts LM124A-LM224A-LM324A which feature 3mV max.)
  • Low input offset current: 2nA
  • Wide power supply range: Single supply: +3V to +30V
  • Dual supplies: ±1.5V to ±15V
