Description
The Infrared (IR) Flame Sensor Module is an inexpensive and easy-to-use component designed to detect fire by sensing the specific infrared radiation (760 nm to 1100 nm wavelength) emitted by flames. It is widely used with microcontrollers like Arduino and Raspberry Pi for fire detection systems and robotics projects.
Specifications:
- Operating Voltage 3.3V to 5V DC
- Detection Range 760 nm to 1100 nm wavelength
- Detection Angle Approximately 60 degrees
- Detection Distance Up to 80cm for a lighter flame (varies with flame size and ambient light)
- Output Type Digital (DO) and Analog (AO)
- Sensitivity Adjustable via an onboard potentiometer
- Indicators Power LED (red) and Output LED (green)
- Dimensions Typically around 32 x 14 mm
