2S 3A 18650 Li-ion Battery Charger BMS Protection Module

Description

The 2S 3A 18650 Li-ion Battery Charger BMS Protection Board is a high-quality module designed to manage and protect 2-series lithium-ion battery packs. This board ensures safe and efficient charging and discharging of 18650 batteries by providing essential protection features such as overcharge, over-discharge, and overcurrent protection. With a continuous discharge current capacity of up to 3A, this board is ideal for various applications including DIY battery packs, power banks, and other portable electronic devices.

Key Features 2s 3A BMS Module:

• Model: 2S 3A 18650 Li-ion Battery Charger BMS Protection Board
• Number of Cells: 2 (in series)
• Working Current: 3A
• Instantaneous Peak Current: 5A
• Overcharge Voltage Range: 4.25-4.35V ± 0.05V per cell
• Over-Discharge Voltage Range: 2.3-3.0V ± 0.05V per cell
• Operating Temperature: -40°C to +50°C
• Internal Resistance: Less than 45mΩ
• Dimensions: 36 x 6 x 1 mm (LxWxH)
• Weight: 0.015 kg (0.03 lb)
• Protection Features: Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection

Applications:

• DIY portable projects
• Power banks
• Flashlights
• E-bikes
• Various electronic devices requiring reliable battery management

Benefits of 2s 3A BMS Module:

• High Efficiency: Ensures optimal charging and discharging, extending battery life.
• Compact Design: Small and lightweight, easy to integrate into various projects.
• Reliable Protection: Comprehensive protection features safeguard your batteries from common issues.
• Versatile Use: Suitable for a wide range of applications, from hobby projects to professional electronic devices.

Why Choose the 2S 3A 18650 Li-ion Battery Charger BMS Protection Board? With its efficient management and protection capabilities, this board is the perfect solution for anyone looking to enhance the performance and longevity of their 18650 lithium-ion batteries. Whether you’re a hobbyist or a professional, this charger BMS protection board ensures your batteries are safe and reliable.
