Mini 360 DC-DC Step Down Module

Description

Mini-360 DC TO DC 4.75V-23V TO 1V-17V Buck converter step down module. Super compact and capable, this DC-DC buck converter can knock down a voltage from 23V to as low as 1V with up to 95% efficiency.

Features:

• MPS MP2307DN buck regulator IC
• Input Voltage 4.75 – 23VDC
• 1.0 – 17VDC selectable output voltage
• 3A surge current, 1.8A continuous rated current
• Maximum conversion efficiency of 95% (5Vin, 3.3Vout ~200mA output)
• 340kHz switching frequency
• 30mV no-load output ripple
• 0.5% load regulation
• 2.5% voltage regulation
• -40 to +85°C operational temperature range
• Built-in 160°C thermal shutdown
• 17x11x3.8mm (0.67×0.43×0.15″)
