XL6009 Boost Converter Module DC to DC

XL6009 DC to DC Step-up converter module is a non-isolated step-up (boost) voltage converter featuring adjustable output voltage and high efficiency. XL6009 module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance. It equips 4A high-efficiency MOSFET switches, so as to provide a conversion efficiency of up to 94%.

• Input voltage: 3-32 v
• Output voltage: 5v-35 v
• Input current: 4 a (Max), no-load 18 ma
• Size: 44.7 (mm) x21.7 (mm)
• Efficiency: < 94% (the lower the pressure difference, the greater the efficiency)
• Output ripple: 50 mv (the bigger the higher the voltage, current and ripple)
